Provides (8) channels of VoIP networking capability between SL2100 sites. Additional SLNet 8-Channel Licenses can be added to a site – depending on the network traffic requirement.
A maximum of (16) SLNet 8-Channel Licenses is allowed per site.
A minimum of (1) SLNet 8-Channel License is required for each site in the network.
Maximum of (50) sites in a network.
Can also be used to network SL2100 sites with SL1100 sites. However, the maximum number of sites that an SL1100 system may be networked to is 4.
Features include:
Centralized Network Attendant
Centralized or local InMail voice mail system
Intercom between all sites
Share trunks between all sites
BLF and Centralized Park Orbits across network
Maximum combined network trunk and station ports total is 256.
Each system in the network must be equipped with an appropriate quantity of VoIP channels to handle that system’s network traffic. There are (8) VoIP channels built into the CPU. Additional VoIP channels can be added with the VoIP Daughter Board and one or more 16-Channel VoIP Licenses. See page 3 for details.
The quantity of VoIP channels that is required for each SLNet site is determined by the amount of VoIP traffic at that site (IP phones, SIP trunks, and SLNetworking).
