16.00” length
EnGenius
655216009776
ENG-ECS5512
24-Port Cloud Managed Multi-Gigabit L2
$ 659
Out of stock
Free Delivery
Customer Support
Secure payment method
– Full-featured layer 2+ switching
– 8 100/1000/2500/5000/10000 Base-T GbE ports to serve high-bandwidth devices
– 240 Gbps switching capacity for improved performance
– 4 Dual-Speed 10G SFP+ (fiber) uplink ports to connect at long distances, high speeds & high capacity
– Security – access control list/port security; 802.1X & RADIUS authentication
– IGMP & MLD snooping provides advanced multicast filtering & network efficiency
– 802.3ad link aggregation (LACP) supports traffic load balancing
– Spanning Tree (STP), Rapid Spanning Tree (RSTP) & Multiple Spanning Tree (MSTP)
– Voice VLAN for fast, reliable deployment of VoIP services
– 8 100/1000/2500/5000/10000 Base-T GbE ports to serve high-bandwidth devices
– 240 Gbps switching capacity for improved performance
– 4 Dual-Speed 10G SFP+ (fiber) uplink ports to connect at long distances, high speeds & high capacity
– Security – access control list/port security; 802.1X & RADIUS authentication
– IGMP & MLD snooping provides advanced multicast filtering & network efficiency
– 802.3ad link aggregation (LACP) supports traffic load balancing
– Spanning Tree (STP), Rapid Spanning Tree (RSTP) & Multiple Spanning Tree (MSTP)
– Voice VLAN for fast, reliable deployment of VoIP services
Features
Color: Black
Backplane Bandwidth – Gbps: –
Max PoE Power Consumption – Watts: –
Number PoE Ports: –
Packet Buffer Size – Kb: –
Port Type: Gigabit Ethernet
Rack Mountable: Yes
Total Number of Ports: 12
Number SFP Ports: 4
Total Number of Ports: 28
Number PoE Ports: 8
PoE Support Type: PoE
Managed: Yes
Max PoE Power Consumption – Watts: 410
Switching Capacity – Gbps: 152
Switching Capacity – Gbps: 240
Backplane Bandwidth – Gbps: –
Max PoE Power Consumption – Watts: –
Number PoE Ports: –
Packet Buffer Size – Kb: –
Port Type: Gigabit Ethernet
Rack Mountable: Yes
Total Number of Ports: 12
Number SFP Ports: 4
Total Number of Ports: 28
Number PoE Ports: 8
PoE Support Type: PoE
Managed: Yes
Max PoE Power Consumption – Watts: 410
Switching Capacity – Gbps: 152
Switching Capacity – Gbps: 240
Environmental Features
Energy Star Qualified:
Recycled Packaging:
Recycled Packaging:
Other Features
Country of Origin:
RoHS Compliant:
Type of Packaging: Retail Box
Warranty: 5 Year
Website Link: www.engeniustech.com
RoHS Compliant:
Type of Packaging: Retail Box
Warranty: 5 Year
Website Link: www.engeniustech.com
package dimensions:
4.00” Height
6.00 lbs normal weight
5.53 lbs dimensional air weight
4.63 lbs dimensional ground weight
12.00” Width
Note: The heaviest weight value will be used in calculating shipping charges
package dimensions:
12.00” Width
4.00” height
16.00” length
6.00 lbs normal weight
5.53 lbs dimensional air weight
4.63 lbs dimensional ground weight
Note: The heaviest weight value will be used in calculating shipping charges
