– Elevators
– Parking ramps/lots
– Pools
– Automated Tellers (ATM)
– Area of refuge locations
– Lobbies
– Entryways
– Roadside emergency stations
– Stadiums
– Convention centers
– Campus Security Sites
– Entryways
– Stairwells in Public Buildings
– Enhanced Weather Protection (EWP), EWP products are designed to meet IP66 Ingress Protection Rating, see DOD# 859
– Meets ADA requirements for Emergency Phones:
– Can automatically light the “Call Connected” LED for the hearing impaired
– Transmits a unique location I.D. code or voice announcement
– Grade 2 Braille label for the visually impaired
– Non-volatile digital voice announcer with 16 seconds of voice memory
– Provides contact or switched 12V DC for controlling a strobe light
– Advanced call progress detection
– Handsfree operation
– Phone line powered emergency phone (LDB-3 requires power)
– Non-volatile memory (no batteries required)
– Marine grade 316 stainless steel prevents corrosion
– Dials up to 5 emergency numbers
– Cycles through backup emergency and non-emergency numbers on busy or no-answer
– Hangs up on CPC, silence, busy signal, dial tone, time-out or touch tone command
– Programmable to auto-answer on incoming calls
– Remotely programmable
– Extended temperature range (-15°F to 130°F)
– Central Station Monitoring capability (dials 2 numbers)
– Separate central station voice speed dial number
– High visibility, vandal and weather resistant
– Phone Power: Telephone line powered (24V DC/20mA min)
– LDB-3 Control Module: 120V AC/12V DC 500mA, UL listed adapter provided
– Mounting: Flush mount to Talk-A-Phone ETP towers, wall mounts, boxes and pedestals
– Environmental: -26°C to 54°C (-15°F to 130°F) with 5% to 95% non-condensing humidity
– Material: .125” (11 gauge) brushed stainless steel
– Connections: Color-coded wires with gel-filled butt connectors
