– Provides power and data connection for up to 24 PoE network devices
– Saves installation costs by delivering data and power over existing network cables
– 10/100/1000 Mbps auto-sensing ports automatically detect optimal network speeds
– Four combo small-form-factor pluggable GBIC module slots (SFP) and four RJ45 copper uplinks
– IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports
– Power output up to 30 watts per port
– PoE power budget of 370 watts
– Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras)
– Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
– All RJ45 ports equipped with Auto-MDIX and auto-negotiation support
– Web-based configuration
– Remote reboot/restart
– Supports SNMP management
– Supports VLAN (protocol-based and port-based)
– Supports link aggregation (trunking)
– IGMP Snooping for multicast filtering
– Supports bandwidth control per port
– Supports port mirroring
– Supports two types of QoS: IEEE 802.1p and DSCP
– Broadcast storm control with multicast packet rate settings
– Supports jumbo frames up to 9.6 kBytes
– Store and forward switching architecture
– Full/half duplex operation
– IEEE 802.3x flow control for full duplex
– Supports 8k MAC address entries
– LEDs for power, link/activity and PoE
– Two high-volume cooling fans to ensure perfect ventilation
– Includes 19″ rackmount brackets
