– Provides power and data connection for up to 16 PoE network devices
– Save installation cost by delivering data and power over existing network cables
– 10/100/1000 auto-sensing ports automatically detect optimal network speeds
– Two small form-factor pluggable GBIC module slots (SFP)
– IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports
– Power output up to 30 watts per port
– PoE power budget of 220 watts
– 36 Gbps switch fabric
– Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras, etc.)
– Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
– All RJ45 ports with Auto-MDIX and NWay auto-negotiation support
– Complies with the IEEE 802.3az (Energy Efficient Ethernet EEE) specification
– PoE management functions include PoE port settings, priority, power-on delay, scheduled PoE device restart and PoE device monitoring
– The Powered Device Monitor feature (PDM) restarts any connected PoE device that fails to respond or send out network traffic.
– SNMP Management and Remote Monitoring (RMON)
– SNMP V1, V2C, V3 with RMON groups 1, 2, 3 & 9
– IPv4/v6 dual protocol
– Supports VLAN (tag-based and port-based)
– Provides IEEE 802.1x port-based security
– Supports link aggregation (trunking)
– Supports bandwidth control per port
– Supports port mirroring
– Supports two types of QoS: port-based and DSCP
– Broadcast storm control with multicast packet rate settings
– 512 kBytes buffer memory
– Supports 8k MAC address entries
– Supports jumbo frames up to 9 kBytes
– Supports Rapid Spanning Tree/Spanning Tree protocol
– Store and forward switching architecture
– Full/half duplex operation
– IEEE 802.3x flow control for full duplex
– Configuration via Web browser, Telnet or SSH
– Remote Reboot/restart
– LEDs for power, link/activity and PoE
– Two high-volume cooling fans ensure perfect ventilation
