– Vandal Resistant Features:
– 12 gauge 316 stainless steel faceplate
– Permanent laser etched graphics
– Heavy duty metal hook switch
– Heavy duty metal keypad
– 54? armored handset cable
– T-10 Security Torx drive mounting screws
– Weather Resistant Features:
– Marine grade 316 stainless steel faceplate
– Marine grade 316 stainless steel Torx security screws
– Internally sealed keypad
– Equipped with Enhanced Weather Protection (EWP)
– Faceplate gasket (on EWP models)
– Ring with adjustable volume and cadence
– Hearing aid compatible amplified handset with sealed push button volume control
– Two sets of SPDT 2 Amp relay contacts for door/gate or camera control
– Optional RC-4A for Secure Remote Relay Control, see DOD 582
– SIP compliant
– PoE powered (class 1, <4 Watts)
– Outbound Proxy, Authentication ID, Peer to Peer, VLAN Tagging
– Network downloadable firmware
– 54” armored handset cable
– Enhanced Weather Protection (EWP), EWP products are designed to meet IP66 Ingress Protection Rating, see DOD 859
– Programmable to speed dial up to 250 numbers
– 26 Bit Wiegand input for optional proximity card readers, see DOD 221 and 228
– 26 Bit Wiegand output connect to card reader input of an Access Control System
– Cycles to rollover phone number on busy or no-answer
– Program up to 1,000 keyless entry codes­­­ and/or proximity card numbers
– Keyless entry codes and proximity card numbers can be programmed to only allow access at specific times and day of week
– Event logging with time and date stamp
– Remotely programmable
– Extended temperature range (-40°F to 140°F)
– Zinc plated steel rough-in box with (2) 0.75? conduit knockouts included
– Flush mount using the included rough-in box or surface mount using a Viking VE-5×10 surface mount box (not included, DOD 424)
– Optional VE-LIGHT kit to illuminate the front panel at night, see DOD 428
– Diagnostics (for testing relay)
